5V 雷射激光管激光模組 5mW 紅色 圓點激光頭 可調焦距 水平儀 雷射筆 雷射光筆 激光筆

描述

5V 雷射激光管激光模組 5mW 紅色圓點激光頭 可調焦距 水平儀 雷射筆 雷射光筆 激光筆

用於紅光激光筆，激光手電，激光定位，測距儀，醫療設備，電子製作愛好者等

技術參數

• 型號：LD-G650A03
• 輸出：圓點紅色（650nm）
• 尺寸：Φ12.0x35mm
• 線長：約135mm
• 淨重：13.5g
• 電壓：3.0V-5V
• 電流：40mA(最大)

650nm 5mW 3-5V Red Laser Dot Module Diode w/Driver Plastic Lens

Description：
Parameter :
Class IIIA
Wavelength:650nm
Output Power:5mw
Working Voltage:3 – 5V
Working Temperature:＋15 ℃~＋35 ℃
Laser Shape: Dot
Focusable:Yes
Material and Color:Metal
Operating Current:I < 45mA
Dimensions:12*12*35mm

Feature:
This 650nm laser diode is an industrial electronic component and used for as Industrial testament, Lab, DIY.
It is precise and sensitive optical instrument. Before carrying on some laser DIY activities, please read about the technical information first and protect your eyes before laser ray. Be sure the operator has experience in optics DIY or testing.
Care Instruction:
Please keep the lens clean to make the laser beam clear and bright. Before carrying on some laser DIY activities, please read about the technical information first and protect your eyes before laser ray. Be sure the operator has experience in optics DIY or testing Red wire “”+”” pole; black wire “”-“” pole.
